Price: US$ 14.80/kg

Professional DIN Standard Industrial Fastening Solutions

Brass Hex Set Screws

Engineered for precision positioning and securing applications, our comprehensive range of Brass Hex Set Screws delivers exceptional reliability through advanced manufacturing processes. Manufactured to international standards including DIN 933, BS 1083, and BS 3692, these set screws feature hexagon head configurations in both full and half threaded options. Our complete product line includes standard set screws, socket set screws, metric set screws, hex slotted set screws, and hexagonal set screws available from 3mm to 16mm thread size and up to 100mm in length. These components provide optimal positioning accuracy and mechanical strength for long-term reliability in demanding applications requiring precise component positioning and secure fastening.

Key Specifications

Standards:

DIN 933, BS 1083, BS 3692

Thread Size:

3mm to 16mm

Length Range:

Up to 100mm

International Standards Compliance

DIN 933

German Standard

Manufactured to DIN 933 specifications for hexagon head bolts and set screws, ensuring standardized dimensions and thread specifications for international compatibility.

Standardized hex head dimensions
Precise thread specifications
International compatibility

BS 1083

British Standard

Compliant with BS 1083 British Standard for hexagon head bolts and set screws, providing reliable performance for UK and Commonwealth applications.

British Standard compliance
Commonwealth compatibility
Quality assurance standards

BS 3692

British Standard

Manufactured according to BS 3692 specifications for precision set screws, ensuring accurate positioning and reliable performance in critical applications.

Precision set screw standards
Critical application reliability
Accurate positioning capability

Size Specifications

Thread Sizes Available

3mm 4mm 5mm 6mm 8mm 10mm 12mm 14mm 16mm

Comprehensive thread size range from 3mm to 16mm, covering most standard applications and providing flexibility for various positioning and fastening requirements.

Length Options

Minimum: Standard lengths from 6mm

Maximum: Up to 100mm length

Increments: Standard length increments available

Extensive length range up to 100mm providing flexibility for various application depths and positioning requirements.

Complete Set Screw Solutions

Standard Set Screws

Professional standard set screws manufactured to international specifications, providing reliable positioning and securing capabilities for general industrial applications.

Socket Set Screws

Precision socket set screws featuring internal hex drive for applications requiring flush mounting and high torque capability in confined spaces.

Metric Set Screws

Comprehensive metric set screws designed for international compatibility, featuring ISO metric threading for global standard compliance and interchangeability.

Hex Slotted Set Screws

Specialized hex slotted set screws providing dual drive options with both hexagonal and slotted drive capabilities for versatile installation requirements.

Threading Options

Full Threaded

Complete Threading

Full threaded set screws with threading extending the complete length of the screw, providing maximum thread engagement and holding power for demanding applications.

Maximum thread engagement
Superior holding power
Demanding application suitability

Half Threaded

Partial Threading

Half threaded set screws with threading on portion of the length, providing smooth shank section for applications requiring precise positioning without thread interference.

Smooth shank section
Precise positioning capability
Reduced thread interference

Precision Positioning and Securing Applications

Our comprehensive range of brass hex set screws serves critical applications across precision machinery, mechanical assemblies, positioning systems, securing mechanisms, shaft collars, pulley systems, and specialized equipment requiring accurate component positioning. These components are essential for reliable mechanical connections where precise positioning, secure fastening, and long-term stability are required in demanding precision engineering environments.

Key Benefits

International standards compliance (DIN 933, BS 1083, BS 3692)
Comprehensive size range (3mm to 16mm thread, up to 100mm length)
Full and half threaded options available
Multiple drive configurations (hex, socket, slotted)
Precision positioning and securing capabilities
Brass construction for corrosion resistance and electrical conductivity

Technical FAQ – Brass Hex Set Screws

Which material should be specified?

Specify the brass alloy and condition on the drawing. Free-machining and forging brasses are different choices; steel or stainless steel parts are separate material options, not brass grades. Confirm corrosion and strength requirements for the application.

How do I confirm connection compatibility?

Specify thread diameter, pitch, tolerance class and engagement length, together with the head or nut form. Metric and imperial threads are different systems. Use the applicable dimensional standard or an agreed drawing; a list of standards does not establish compliance for every variant.

What dimensions are needed for selection?

Provide a dimensioned drawing, mating-thread details, length or thickness, head dimensions, finish and quantity. Agree critical tolerances and inspection requirements before production.

What determines suitability and operating limits?

Brass fasteners serve mechanical, electrical and decorative assemblies where the selected grade is suitable. Permitted load and tightening torque depend on alloy, geometry, thread engagement and lubrication. Do not apply steel fastener property classes or torque tables to brass without an engineering assessment.

What finish and inspection documentation should I request?

State the required surface finish, coating thickness where relevant, and critical dimensions on the order. Material certificates, dimensional reports and any specified performance tests should be agreed in the quotation. A reference to a standard is not a declaration of third-party certification.

Can I request a custom part or export quotation?

Send a drawing or clearly dimensioned sample specification, material, quantity and delivery destination. Identify application conditions and required approvals. Brass Parts India can review the requirement and confirm feasibility, price, documentation and lead time for the quoted part.
